銳威W763入墻音箱 REVEL定制音箱

銳威W763入墻音箱參數指標
建議使用放大器功率:10-130 watts RMS
系統靈敏度:89db/2.83v/m
系統阻抗8Ohms
低音單元6.5“(165mm)黑色納米顆粒涂層陶瓷復合(MCC錐盆、聚合物鑄造框架低音揚聲器
高音單元:1“(25.4mm)鋁振膜球頂外置波號輻射的高音揚聲器
高音電平控制：3階
低音邊界補償：開/關
外形尺寸:高276mmx寬212mm
安裝深度:91mm
開孔尺寸:高249mmx寬190mm
重量:2.5kg(凈重)、3kg(含包裝)

DESCRIPTION
6 ½" In-Wall Loudspeaker
HIGH-FREQUENCY DRIVER COMPONENTS
1" aluminum dome swiveling high-output tweeter with waveguide
LOW-FREQUENCY DRIVER COMPONENTS
6 ½" Micro-Ceramic Composite (MCC) Cone, Cast-Aluminum Frame High-Output Woofer
LOW FREQUENCY EXTENSION
High Frequency Extension: 3-position HF level control / Low Frequency Extension: LF boundary compensation
MOUNTING
C-2 mounting mechanism • Compatible with wall material thickness range: 0.5" – 1.0" (1.3 cm – 2.5 cm)
DEPTH
Mounting depth: 3.6" (9.1 cm)
WEIGHT
5.4 lb (2.5 kg) / Shipping weight: 6.5 lb (3.0 kg)
FEATURES
Cutout dimensions (H x W): 9.8" x 7.3" (24.9 cm x 18.5 cm) • Includes zero-bezel magnetic grille • Grille finished dimension (H x W): 10.8" x 8.3" (27.3 cm x 21.1 cm)
